KTM 390 ’18-’24 Duke Cruise Control Cruise Kit

Description

Compatibility

• 2018-2020 390 Duke
• 2021-2024 390 Duke

*Please ensure you note your bike year at checkout

Choice of switch

Factory 890

A factory KTM 890 combination switch is provided. This has all the same features, plus cruise control. The combination switch is modified and rewired to match the 390 plugs.

Triple Button Switch

A 3 button switch for controlling the cruise functions is included. Fully watertight and durable. Mounts directly to standard 22mm handlebars with a fully opening bracket. This option provides 3 buttons.

• Resume / Increase
• Cancel
• SET/ Decrease

LED lights and other upgrade compatibility

This kit is 100% compatible with any aftermarket lights and kits. No wire splicing or messing with brake wires.

Cruise Stop Conditions

We know it’s paramount on motorbikes to quickly kill the cruise control in as many situations as possible. Our module will disengage cruise control for any one of the following conditions

• Engine RPM signal falls below 1000 or above defined max
• Front brake lever**
• Bike transmission is in first gear or neutral
• Any one of the required CANBUS packets are not updated within 1000 milliseconds
• A difference of 10% between the front and rear wheel speeds

**The 390 CANBUS does not provide rear brake or clutch lever information

Configurability

The module has a weather tight USB-C connector for changing various settings such as speed increment size, PID gain, and throttle limits.

Diagnostic Port

This kit uses the diagnostic port of your bike. If you want a second port for OBD and Off Road dongles see addon section.

Manual /  Install

Click here for PDF Installation manual
